Structure:
It consists of a spiral housing (steel), direct drive motor with a radial impeller. The inlet is equipped with a flange to install it on a wall bracket or filteringunit. It is recommended to install silencers type TK at the inlet and outlet of the fan.
With silencer at intake and outlet:
Motor protective switches, rotational governors, installation equipment – are described in cards ACCESSORIES.
Max. temperature of the transported air +140 F; max. temperature in the work-zone of the fan +104 F.
Max. dustiness of the transported air should not exceed 0.37 oz/ft³.
